A350-28 display

The A350-28 is a multifunctional device for flow and volume measurement.

• Universal inputs (HTL / RS422) for encoders / VSE flow meters
• 186 x 64 pixel graphic display with touch function
• Bright, high-contrast display with result-based colour options
• Emulation of a 7-segment display with symbols and units
• Intuitive and easy parameterisation using plain text and touchscreen or via a PS232 interface
• Auxiliary voltage output 5/24 VDC for encoder supply
• Input frequency up to 1 MHz
• Linearisation with 24 support points
• 16 bit analog output 0/4 ... 20mA, 0 ... 10V and - / + 10V; 20ms reaction time
• Numerous functions such as scaling, filters, startup bridging
• Standard installation housing with 96 x 48 mm and protection class IP65
